| System |
| Main Processor |
Dual Cortex A53 |
| Operating System |
Embedded LINUX |
| Video |
| Input |
16CH(12MP/8MP/5MP/4MP/3MP/1080p/1280x1024/960p/720p/D1) |
| Output |
1*HD,1*VGA |
| Audio |
| Input |
1 Port RCA, support 16CH IPC audio input |
| Output |
1 Port RCA(Linear, 1kΩ), HD output |
| Audio Bit Rate |
64kbps |
| Audio Compression standard |
G711U, G711A, AAC, MP2L2 |
| Intercom |
support (two-way) |
| Alarm |
| Sensor Input |
N/A |
| Output |
N/A |
| Motion Detection |
16 Channel, MD Zones: 396 (22 × 18) |
| Trigger Events |
Recording, Email, FTP, Snapshot and Screen Tips, Pop-up Window, Buzzer, Notify Surveillance Center |
| Display |
| HD Output1 |
4K(3840*2160)/2K(2560*1440)/1920*1080/1280*1024/1280*720/1024*768 |
| HD Output2 |
N/A |
| VGA |
1920x1080,1280x1024,1280x720,1024x768 |
| Display Split |
16CH/13CH/10CH/9CH/8CH/6CH/4CH/2CH/1CH |
| Digital Zoom |
YES |
| OSD |
Camera Title, Time, Recording, Motion Detection, Event Alarm |
| Event |
| Smart Event |
Intrusion Detection, Line Crossing Detection, Region Entrance, Region Exiting, Loitering Detection, People Gathering Detection, Face Detection, Illegal Parking Detection, Line Crossing Count, LPD(License Plate Detection), Abandoned Object Detection, Removed Object Detection, Heat Map, Fire Detection, Video Metadata |
| Nomal Event |
Motion, Video Tampering, Video Loss, Audio Detection, Scene Change |
| Recording |
| Video Compression |
H265/H264/H265+/H264+ |
| Resolution |
12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280x1024/960P/720P/D1/2CIF/CIF |
| Record Rate |
PAL: 12MP@10CHx25fps,8MP@16CHx25fps,5MP@16CHx25fps,4MP@16CHx25fps,3MP@16CHx25fps,1080P@16CHx25fps,960P@16CHx25fps,720P@16CHx25fps,D1@16CHx25fps
NTSC: 12MP@10CHx30fps,8MP@16CHx30fps,5MP@16CHx30fps,4MP@16CHx30fps,3MP@16CHx30fps,1080P@16CHx30fps,960P@16CHx30fps, 720P@16CHx30fps,D1@16CHx30fps |
| Record Mode |
Manual\Timer\Motion Detection\Event |
| Playback & Backup |
| Local Sync Playback |
1CH 12MP@30fps, 1CH 8MP@30fps, 2CH 5MP@30fps, 4CH 4MP@30fps, 7CH 1080P@30fps, 16CH 720P@30fps, 16CH D1@30fps |
| Decode Capability |
1080P@210fps |
| Remote Sync Playback |
YES |
| Search Mode |
Video, Picture, Event, Pedestrian, Vehicle, Face, License Plate |
| Playback Functions |
Play, pause, fast forward, rewind, previous frame, next frame, electronic zoom, clip, audio |
| Backup Mode |
USB Device/Network |
| Network |
| Interface |
1 x RJ45(10M/100M/1000M Adaptive Ethernet Interface) |
| Incoming Bandwidth |
128Mbps |
| Outgoing Bandwidth |
80Mbps |
| Network Functions |
IPv4/IPv6/TCP/IP/HTTP/HTTPS/UPnP/DNS/NTP/SMTP/DHCP/FTP/DDNS/RTSP/RTCP/p2p/PPPOE/SNMP |
| Onvif |
Profile S, Profile T, Profile G, Profile M |
| Web Browser |
Edge, IE8-11, Google Chrome, Firefox, Safari |
| CMS Software |
Support Windows 10/Windows 11/MAC OS |
| Cloud Support |
Yes |
| Smart Phone |
iPhone, Android |
| POE |
8 x Independent 100Mbps POE Network Interfaces(Output Power AT mode 30W per Interface, AF mode 15W per Interface), 45/78 line order, Total Power Output 72W, Support Plug and Play, Support network cable extended mode Max. 200M |
| WIFI |
N/A |
| Storage |
| Interface Type |
1 SATA Hard Disk Interface (3.5" SATA) |
| Capacity |
Up to 16TB for each disk |
| eSATA |
N/A |
| General |
| Language UI |
Simplified Chinese, Traditional Chinese, English, Polski, Czech, Arabic, German, French, Portuguese, Spanish, Italian, Hungarian, Korean, Dutch, Greek, Janpanese, Ukrainian, Kazakh, Hebrew |
| USB Interface |
Front panel: 1×USB 2.0; Rear panel: 1×USB 2.0 |
| RS485 |
N/A |
| Power consumption |
DC48V ≤ 9W (Without Hard Disk) |
| Working Environment |
-10℃～55℃, 10%～90%(humidity) |
| Product Dimension(W×D×H) |
260X230X43(mm) |
| Net Weight |
0.93kg(without HDD) |
| Gross Weight |
1.75kg(without HDD) |
