WiFi Technology
-
Standard: WiFi 7 (802.11be)
-
Spatial Streams: 4
-
Max Data Rate:
-
5 GHz: Up to 4.3 Gbps (BW240)
-
2.4 GHz: Up to 688 Mbps (BW40)
-
-
Antenna Gain:
-
5 GHz: 5 dBi
-
2.4 GHz: 4 dBi
-
-
MIMO Technology: 2x2 MU-MIMO (DL/UL) for both 2.4 and 5 GHz
-
Max TX Power:
-
5 GHz: 24 dBm
-
2.4 GHz: 23 dBm
-
-
Coverage Area: Up to 115 m² (1,250 ft²)
-
Max Client Capacity: 200+ concurrent users
Networking & Power
-
Uplink Interface: 1x 2.5 GbE RJ45 port
-
Power Consumption: Max. 13W
-
Voltage Range: 42.5–57V DC
Advanced Features
-
Wireless Meshing
-
Band Steering, Fast Roaming (802.11r), BSS Transition (802.11v), and RRM (802.11k)
-
Hotspot Capabilities: Captive portal with custom branding, voucher and payment-based authentication, PPSK, and external portal server support
-
Security & Access Control: Guest network isolation, client device isolation, RADIUS over TLS (RadSec), dynamic VLANs
-
Network Management: WiFi scheduling, bandwidth limiting, and advanced radio management
Software & Management
-
Platform Compatibility:
-
UniFi Network: Version 9.0.114+
-
Mobile Apps:
-
iOS™ 10.20.2+
-
Android™ 10.21.7+
-
-
-
Enclosure: UV-stabilized polycarbonate
-
Status LED: White/Blue system indicator
-
Compliance: NDAA-compliant; certified CE, FCC, IC
Environmental Tolerance
-
Operating Temperature: -30°C to 40°C (-22°F to 104°F)
-
Humidity: 5% to 95% non-condensing
