18Gb Pure HDMI

Despite its petite size, the MX-H2-0404-10 is a powerhouse of video distribution. With 18Gb per second performance and 4K60 HDR compatibility across high bandwidth HDMI cables, this compact matrix switcher packs a serious punch!

ARC Capture

The MX-H2-0404 is the perfect companion for displays with audio return channel signals. It makes connecting systems easier than ever, providing both analog and digital outputs to ensure maximum efficiency of transfer.





Onboard Control

Unlock the power of control with Netvio's H2-0404, an advanced matrix switch that includes integrated control and free apps for both Apple and Android devices. Download today to experience hands-on operation using our Demo mode - no purchase necessary!

Drivers for Control

Netvio has you covered with our MX-H2-0404-10! Our integration drivers provide seamless integration to major control systems such as Control4, Crestron, RTI, Elan and Savant. Get started by downloading the driver today – it's just a few clicks away!

Specifications

VIDEO

• Encoding Data Rate

• HDMI: Max 17.82Gbs

• Max Video Transmission

• 3840x2160 60fps 4:4:4 8b

• ​HDMI (Inputs/Outputs)

• Supporting HDMI 2.0b resolutions including 3840x2160 60fps HDR.

• ​Max Pixel Clock

• 600MHz / 600Mcsc

• HDR Compatibility

• HDR10, HDR10+, Hybrid Log-Gamma, Dolby Vision

• Scaler Function

• 4K to 1920x1080 progressive
• Modes include, pass-through (no scaling), Fixed 4K → 2K, Automatic

• ​HDCP

• Inclusive up to 2.2

AUDIO

• Audio Formats:

• LPCM 2ch, LPCM 5.1, LPCM 7.1, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS Master

• Audio Outputs:

• 4no. 2ch variable line level stereo analog audio jack sockets.
• 4no. S/PDIF audio via female RCA socket, S/PDIF digital audio supporting uncompressed PCM and non-linear PCM-encoded bitstreams.

• Audio Return Channel:

• ARC capture from compatible display. Output through described audio outputs.

COMMUNICATION & CONTROL

• HDMI:

• CEC, DDC

• RS-232:

• Supports directvia a DB9 socket on the rear panel.

• LAN:​

• Local discovery and API console via Netvio 360 & Netvio Go APP,
• 3rd-party integration via public API

• Drivers & Control

• Drivers available for control systems including C4, Crestron, RTi & Elan.
• Discovery, configure, optimise, design via Netvio 360 utility.
• Full spectrum AV control via FREE Netvio application for Apple & Android devices.

• ​EDID

• Automatic, Onboard pre-sets, Copy sync (RX)

ENVIRONMENTAL

• Storage

• 20°C / +60°C | 20% - 90% RH
• Operating
• 0°C / +40°C | 20% - 90% RH

OTHER INFORMATION

• Power Supply:

• External 12v PSU. supporting worldwide AC voltages (e.g. 120V/60 USA, 230V/50 UK)

• FREE Software & Control

• Netvio 360 utility - discovery, configure, optimise, design, control
• Netvio GO - Full spectrum AV control

• Weights & Dimensions:

• Rack Units: Compact 1U
• Height: 44mm
• Width: 220mm
• Depth: 105mm
• Weight: 0.8kg

• In the Box:

• Phoenix Connectors
• Remote Control
• Regionalised Power Lead
• Regulations
• Safety Approvals: CE, UKCA, FCC, RoSH

• Warranty

• 5-Year standard warranty
