Akuvox NS-2 IP Converter To 2 Wires, 6 Channels, DIN Mount

Trade Only Product

AK-NS-2
In stock
Brand Akuvox
Model NS-2
Operation mode Power, video, audio and network through 2 technology
Outputs 6 channels of 2 wires
Cascade 1 channel for cascading of AK-NS-2
Communication 2 threads technology (up to 6 devices)
Network interface Ethernet 10/100 BaseT
Power DC 48 V | 1.25 A max.
Temp. operation -20º C ~ +50º C
Dimensions 161 (W) x 90 (H) x 65 (D) mm
Weight 500 g

Datasheet (AK-NS-2_EN.pdf, 776 Kb) [Download]
